Wholesale Wallbox EV Charger, Smart & Efficient

Wallbox EV Charger – Drive clean, go green, help you win green! Small and exquisite design does not take up much space, but has powerful performance, can quickly replenish the power for your car, make clean driving easier and more efficient.

The Smart App connects via WiFi or Bluetooth. No matter where you are in your home, you can easily manage the charging status, timer charging and check the energy consumption report remotely.Wallbox EV Charger makes every home charging smarter and more environmentally friendly.

Description
Detail
Videos
Download
Application

Adjustable power up to 48Amp (11.5kW)

The current adjustment range is 16A up to 48A, and if the charger is installed on a circuit with a current rating lower than its maximum rating, the lower maximum current can be set manually using the convenient current selector.

Suitable for all electric vehicles

Equipped with Type 2, CCS2, and GB/T connectors, our chargers are compatible with most electric vehicles in Europe, Southeast Asia, and China. With built-in WiFi and Bluetooth, the integrated smart app allows you to control charging remotely, schedule sessions, and monitor energy usage. RUIHUA makes EV charging smart, seamless, and globally ready.

Supports static power sharing

Have more than one EV? Built-in load balancing lets you distribute power to each connected charger to charge multiple EVs at the same time, avoiding costly electrical upgrades by connecting up to 25 chargers to a single circuit.

Wi-Fi and Bluetooth connectivity

Featuring both Wi-Fi and Bluetooth connectivity, the charger allows seamless control through a smart app-even without an active internet connection. Easily schedule charging sessions, manage energy usage, and stay in charge of your EV anytime, anywhere. RUIHUA makes reliable, eco-friendly home charging smarter than ever.

wallbox eV charger spec sheet

Specifications	Model	RHAC7K-XC	RHAC11K-XC	RHAC21K-XC
Input	Powersupply	1P+N+PE	3P+N+PE	3P+N+PE
	Rated Voltage	230V+15%	400V+15%	400V+15%
	Rated Current	32A	3*16A	3*32A
	Frequency	50/60 Hz	50/60 Hz	50/60 Hz
Output	Output Voltage	230V+15%	400V+15%	400V+15%
	Maximum current	32A	3*16A	3*32A
	Rate Power	7kw	11kw	22kw
Userinterface	charge connector	Type 2 cable
	Cable Length	5 m
	LED Indicator	Green/blue/Red
	Lco Display	4.3 inch LcD
	RFID Reader	MifarelsO/IEC14443A
	Starting Methods	Plug&Play/RFiD card/App
	Emergency stop	Yes
Network connection	LAN	Yes
	4G	optional
	wifi	Yes
	Bluetooth	Yes
	OCPP	OCPP 1.6J
Safety Measures	Energy Meter	Yes
	RCD	6mADC
	Ingress Protection	IP54
	ImpactProtection	lk10
	Electrical Protections	Overcurrent protection Residual current protection Surge protectionOver/Under voltage protectionOver/under Frequency protection overtemperature protection
	Certification	CE/CB
	Certification Standards	ENIEC 61851-1:2019,1EC61851-1:2017,EN61851-21-2:2018
	Warranty	2 Years
OperatingConditions	Installation	Wall-mount/Pole-mount (optional)
	Operating Temperature	-30°C~+50°C
	Humidity	5%~95%
	Altitude	<2000m
Packaging	ProductDimension		350250122 mm (HWD)
	Package Dimension		550350220 mm(L’W’H)
	Net welght	6.5 kg	7.skg	9.skg
	Gross Weight	7.5kg	8.5kg	10.5kg
	others		Carton
